Key Specifications
- CPU Socket: AMD Socket AM5
- Chipset: AMD X870E
- Processor Support:
- AMD Ryzen™ 9000 Series
- AMD Ryzen™ 8000 Series
- AMD Ryzen™ 7000 Series
Memory
- 4× DDR5 DIMM Slots
- Supports up to 256GB DDR5
- Memory speeds up to 9000 MT/s (Overclocked)
- Dual-Channel Architecture
- Supports AMD EXPO™ & Intel XMP
Expansion Slots
- 1× PCIe 5.0 x16 Slot
- 1× PCIe 4.0 x16 (x4 mode)
Storage
- 4× M.2 Slots
- 1× PCIe 5.0 x4 NVMe
- 3× PCIe 4.0 NVMe
- 4× SATA 6Gb/s Ports
Networking
- Wi-Fi 7 (Qualcomm QCNCM865)
- Bluetooth® 5.4
- Realtek® 5GbE LAN
Graphics Outputs
- 2× USB4 Type-C® (DisplayPort Alt Mode)
- 1× HDMI 2.1
- Supports up to 4K 240Hz (DisplayPort via USB4) and 4K 60Hz (HDMI) (depending on CPU graphics)
USB Connectivity
- 2× USB4 Type-C® (40Gbps)
- USB 3.2 Gen 2
- USB 3.2 Gen 1
- USB 2.0
Audio
- Realtek® ALC1220 High Definition Audio
- 7.1-Channel HD Audio
- Optical S/PDIF Out
Cooling & DIY Features
- Advanced VRM Heatsinks
- M.2 Thermal Guards
- Smart Fan 6
- EZ-Latch Design for M.2 & PCIe
- Q-Flash Plus
- Debug LEDs
Power Design
- 14+2+2 Twin Digital VRM
- 8-Layer PCB
- 2X Copper PCB
- Premium Chokes & Capacitors
Special Features
- X3D Turbo Mode 2.0
- D5 Bionic Corsa Memory Optimization
- PCIe 5.0 Graphics & Storage
- Ultra Durable Components
- AI Performance Optimization
Operating System
- Windows 11 64-bit
Form Factor
- ATX
- Dimensions: 30.5 × 24.4 cm
Source: Official GIGABYTE Specifications.
