Key Specifications
General
- Brand: GIGABYTE
- Model: X870 GAMING X WIFI7
- Chipset: AMD X870
- Socket: AMD AM5
- Form Factor: ATX
- Dimensions: 30.5 × 24.4 cm
- CPU Support: AMD Ryzen 9000 / 8000 / 7000 Series Processors
Memory
- Memory Type: DDR5
- Memory Slots: 4 × DDR5 DIMM
- Maximum Capacity: Up to 256GB
- Maximum Capacity per DIMM: 64GB
- Memory Architecture: Dual Channel
- Memory Speed: Up to DDR5-8200 MT/s (OC)
- Memory Support: Non-ECC Unbuffered DIMM
- Overclocking Support: AMD EXPO / Intel XMP
Expansion Slots
- 1 × PCIe 5.0 x16 — CPU integrated
- 2 × PCIe 3.0 x1
- PCIe x16 slot supports graphics cards or NVMe SSD
- PCIe configuration depends on the installed processor
Storage
- 3 × M.2 slots
- 1 × M.2 PCIe 5.0 x4/x2
- 1 × M.2 PCIe 4.0 x4/x2
- 1 × M.2 PCIe 4.0 x2
- 4 × SATA 6Gb/s
- M.2 EZ-Latch Click / EZ-Latch Plus
- M.2 Thermal Guard
Graphics
- 2 × USB4 Type-C with DisplayPort output
- USB4 Maximum Resolution: 3840 × 2160 @ 240Hz
- 1 × HDMI 2.1
- HDMI Maximum Resolution: 4096 × 2160 @ 60Hz
- DisplayPort 1.4
- HDR / HDCP 2.3 support
- Graphics output depends on CPU
Networking
- LAN: Realtek 2.5GbE
- LAN Speed: 2.5Gbps / 1Gbps / 100Mbps
- WiFi: WiFi 7
- WiFi Controller: MediaTek MT7925 / Realtek RTL8922AE depending on PCB revision
- Wireless Bands: 2.4GHz / 5GHz / 6GHz
- Bluetooth: 5.4
- WiFi Standard: 802.11a/b/g/n/ac/ax/be
- Antenna: Ultra-High Gain Antenna
- WIFI EZ-Plug: Supported
Audio
- Audio Codec: Realtek Audio CODEC
- Audio: High Definition Audio
- Channels: 2 / 4 / 5.1 / 7.1-channel
- High-End Audio Capacitors
USB & Connectivity
- 2 × USB4 Type-C — up to 40Gbps with DisplayPort Alt Mode
- 1 × USB 3.2 Gen 2 Type-A
- 3 × USB 3.2 Gen 1
- 4 × USB 2.0
- 1 × Front USB-C 3.2 Gen 2×2 — up to 20Gbps
- 1 × HDMI 2.1
- 1 × RJ-45 2.5GbE LAN
- 2 × WiFi Antenna Connectors
- Audio connectors
- Q-Flash Plus Button
Cooling
- 6 × PWM/DC Fan Headers
- CPU / Pump / System Fan support
- Smart Fan 6
- Dual Fan Curve Mode
- Temperature monitoring
- VRM Thermal Armor Advanced
- M.2 Thermal Guard Extended
RGB Lighting
- 3 × Addressable RGB Headers
- 1 × RGB LED Header
- GIGABYTE RGB Fusion support
Power & VRM
- VRM: 16+2+2 Twin Digital VRM
- PCB: 6-Layer PCB
- PCB Design: 2X Copper
- Premium Chokes & Capacitors
- CPU Power: 8+4 Pin CPU Power
- Main Power: 24-Pin ATX
- UD Solid Pin Power Connector
